Specification
LCD
10-inch 12K Mono LCD
SYSTEM
EL3D-4.0
SLICER SOFTWARE
ChituBox
TECHNOLOGY
MSLA Stereo lithography
LAYER THICKNESS
0.01-0.2mm
PRINTING SPEED
MAX 150mm/H
Z AXIS ACCURACY
0.02mm
XY RESOLUTION
19*24um (11520*5120)
BUILD VOLUME
218.88mm(L)*122.88mm(W)*220mm(H)
LIGHT SOURCE
COB Light Source + Fresnel Collimating Lens(wavelength 405nm)
LANGUAGES
Chinese, English, Japanese, Dutch, Korean, French, German, Russian, Italian, Spanish, Turkish, Portuguese
CONNECTIVITY
USB Interface & WiFi
OPERATION
4.0-inch Capacitive Touch Screen
POWER REQUIREMENTS
100-240V 50/60 Hz 24V 6A
OTHER FUNCTIONS
Tilt Release Technology,
One-Click Self-Check,
One-Click Automatic Leveling,
AI Camera (Empty Build Plate Detection/Warp Detection/Real-Time Monitoring & Time-Lapse Recording),
Smart Mechanical Sensor (Resin Shortage Alarm/Residue Detection Alarm/Leveling Failure Alarm),
Power-Loss Resume Printing
PRINTER DIMENSIONS
327.4mm(L)*329.2mm(W)*548mm(H)
RESIN
Supports most resins on the market (water-washable, standard, ABS-like, plant-based, etc.)
HEAT DISSIPATION METHOD
4 copper heat pipes + single fan
